| 구분 | EP-2123FS | EP-2243FS | EP-3163FS | EP-4643FS | ||||
|---|---|---|---|---|---|---|---|---|
| 이미지 |  |
 |
 |
 |
||||
| 플랫폼 | Rack Mount | Rack Mount | Rack Mount | Rack Mount | ||||
| 폼 팩터 | 2U | 2U | 3U | 4U | ||||
| RAID 컨트롤러 | Single / Dual (Active) | Single / Dual (Active) | Single / Dual (Active) | Single / Dual (Active) | ||||
| 호스트 인터페이스 (선택) | 16Gb FC | 12Gb SAS | 16Gb FC | 12Gb SAS | 16Gb FC | 12Gb SAS | 16Gb FC | 12Gb SAS |
| 호스트 포트 수 (선택) | 4 / 8 | 2 / 4 | 4 / 8 | 2 / 4 | 4 / 8 | 2 / 4 | 4 / 8 | 2 / 4 |
| 디스크 인터페이스 | 12Gb SAS/SATA/SSD | 12Gb SAS/SATA/SSD | 12Gb SAS/SATA/SSD | 12Gb SAS/SATA/SSD | ||||
| 디스크 드라이브 수 | 12 (3.5”/2.5”) | 24 (2.5”) | 16 (3.5”/2.5”) | 64 (3.5”/2.5”) | ||||
| 디스크 드라이브 확장 | 512 (Scale-Up) | 512 (Scale-Up) | 512 (Scale-Up) | 512 (Scale-Up) | ||||
| 프로세서 | 1.2GHz Dual-Core | 1.2GHz Dual-Core | 1.2GHz Dual-Core | 1.2GHz Dual-Core | ||||
| 캐시 메모리 | 4GB~8GB / 8GB~16GB | 4GB~8GB / 8GB~16GB | 4GB~8GB / 8GB~16GB | 4GB~8GB / 8GB~16GB | ||||
| 캐시 데이터 보호 (옵션) | ▪ Battery Backup Module (BBM) ▪ Flash-based Backup Module (FBM) |
▪ Battery Backup Module (BBM) ▪ Flash-based Backup Module (FBM) |
▪ Battery Backup Module (BBM) ▪ Flash-based Backup Module (FBM) |
▪ Battery Backup Module (BBM) ▪ Flash-based Backup Module (FBM) |
||||
| RAID 레벨 | 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, 00, 100, Single Disk, JBOD | 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, 00, 100, Single Disk, JBOD | 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, 00, 100, Single Disk, JBOD | 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, 00, 100, Single Disk, JBOD | ||||
| 전원공급장치 | 400W x 2 (Redundant) | 400W x 2 (Redundant) | 500W x 2 (Redundant) | 1100W x 2 (Redundant) | ||||
| 시스템 관리 | Web GUI, CLI, LCD Panel | Web GUI, CLI, LCD Panel | Web GUI, CLI, LCD Panel | Web GUI, CLI, LCD Panel | ||||
| 확장 스토리지 (선택) | 2U-12Bay JBOD (3.5”/2.5”) | 2U-24Bay JBOD (2.5”) | 3U-16Bay JBOD (3.5”/2.5”) | 4U-64Bay JBOD (3.5”/2.5”) | ||||
| 주요 기능 | ▪ Multiple LUNs ▪ Global/Dedicated Hot Spare Disk v ▪ Online Rebuild ▪ Multiple RAID Selection ▪ Online Array Roaming ▪ Online RAID Level/Stripe Size Migration ▪ Online Capacity Expansion ▪ Online Volume Set Growth S.M.A.R.T. ▪ HDD Xfer Speed Test ▪ Multiple Pairs SSD/HDD Disk Clone ▪ Multi-Path I/O ▪ Dual-Active Controller Cache Mirroring ▪ Redundant Flash Image for Controller Availability ▪ Intelligent Power Management ▪ SNMP Manager ▪ E-mail Notification |
|||||||
